Ifor Williams Trailers GH Plant Range

Ifor Williams Trailers GH Plant Range

The GH range is the latest addition to the plant trailer range and it comprises of six platforn options; GH64, GH94, GH1054, GH106, GH126 and the GH146Tri.

Features & Options
Standard features on all models include, walk-on steel treadplate mudguards, spring assisted ramp*** with integrated ramp supports, bucket rest, heavy duty jockey wheel and five pairs of 500kg lashing points per trailer. Coupling eye options are also available as an alternative to the standard coupling fitted to the trailer.

***Not on Sliding Skids

Some models in the range:

GH64

This is the smallest of the GH plant trailer range. With a bed size of 1.88m x 1.23m (6’ x 4’) and a payload of 1130kg (gross weight 1500kg), the GH64 is designed for smaller items of plant such as micro-excavators. Compact yet robust, this is a neat and convenient single axle trailer that can be towed behind a car. As with all GH models, its galvanized welded construction and leaf spring suspension ensures it will withstand tough conditions. GH64 model is available with two ramp options, a 1.2m (3’9”) ramp with mesh infill or a longer 1.45m (4’9”) bevelled ramp with no infill.

GH94

The GH94 comes in two versions – most popular is a beavertailled version on 165R13C tyres – known as GH94BT. Also available is a GH94 with a flat bed on 195/55R10C tyres. The Beavertail feature means that the excellent loading angle of 13˚ is maintained during loading. The GH94 and GH94BT are extremely versatile plant trailers. A 24mm thick platform makes them particularly suitable for transporting a wide selection of plant, including tracked excavators, and many items of wheeled equipment such as rollers and a variety of access platforms.

The 2.79m (9’) length of the GH94 and GH94BT provides ample loading space behind the rear axle. This enables a full range of mini-excavators to be loaded along with machines with a more central centre of gravity, such as hi-tip dumpers.

GH1054

The GH1054 is only available with a beavertailled feature and offers one of the highest payloads ever produced by Ifor Williams Trailers. With its robust, welded construction and heavily treaded 185/70R13C tyres, the GH1054 is a rugged trailer for demanding conditions. A 24mm platform makes the GH1054 particularly suitable for transporting a wide selection of plant, including tracked excavators, and many items of wheeled equipment such as rollers and a variety of access platforms.The GH1054 is a rugged trailer for demanding conditions.

Specifications:

Optional accessories:

• Aluminium treadplate
• Spare wheel kit
• Winch kit
• Toolbox Kit
• Lashing lugs
