Ifor Williams Trailers Livestock P*G
Ifor Williams Trailers Livestock P*G
Easy to tow, reverse and manoeuvre, the trailers will meet the needs of the most serious of farming professionals. They are ideal for those who regularly attend agricultural shows with their prize animals.
The distinctive steel roof channels give a strong and rigid frame to which the aluminium side panels and heat-reflecting roof are secured. With single axle beam, leaf sprung suspension and galvanized steel chassis, these trailers differ only in size to their larger cousins.
With a maximum gross weight of 1400kg, they can be towed by most large family cars. They provide a payload of 1010kg for the 6’ long version (4’ headroom) and 960kg for the 8’ long version (4’ headroom). Both models offer 4’ and 5’ of headroom with a width of 4’.
Key features
- Front inspection door
- Beam Axle with Leaf Spring Suspension
- Lockable locking head
- Spare wheel and carrier
- 50mm locking ball coupling
- Larger side vents and flaps
- Aluminium ramp side gates
- Loading ramp
Specification
| Model | Tyres | Gross Weight | Unladen Weight | Internal Length | Internal Width | Overall Length | Overall Width |
|---|---|---|---|---|---|---|---|
| P6 4’ H/R (Single Axle) | 165R13C | 1400kg | 380kg | 1.80m | 1.23m | 2.95m | 1.73m |
| P6 5’ H/R (Single Axle) | 165R13C | 1400kg | 400kg | 1.80m | 1.23m | 2.95m | 1.73m |
| P8 4’ H/R (Single Axle) | 165R13C | 1400kg | 427kg | 2.42m | 1.23m | 3.51m | 1.73m |
| P8 5’ H/R (Single Axle) | 165R13C | 1400kg | 452kg | 2.40m | 1.23m | 3.51m | 1.73m |
Optional extras
- Small cross division
- Propstand kit
- Wheel chock kit
For more information on the P*G range of trailers, see: https://www.iwt.co.uk/products/livestock/p6-and-p8
There are many different options, specifications and add-ons for these trailers. Contact Dalton's so we can help to ensure that you have the perfect trailer for your needs.
More Details?
If you'd like more information about the Ifor Williams Trailers Livestock P*G, please call 01570 470022 or Email us.
